High Speed Single-Layer Bubble Wrap Machine

High Speed Single-Layer Bubble Wrap Machine

High Speed Single-Layer Bubble Wrap Machine
High Speed Single-Layer Bubble Wrap MachineHigh Speed Single-Layer Bubble Wrap MachineHigh Speed Single-Layer Bubble Wrap MachineHigh Speed Single-Layer Bubble Wrap MachineHigh Speed Single-Layer Bubble Wrap Machine
CategoriesPE air bubble film machine
AlbumView larger image
BrandVinot
ModelDY-1200
FOB portningbo
Terms of PaymentL/C, Western Union
Download DOC
Update Time2018-05-24
Detail Information
Automatic PE Air Bubble Wrap Film Making Machine With 1200mm Film Width

.Feature

This air crew adopts the disposable shaping craft. It is our factory that draws domestic and international advanced technology extensively, through a large number of production practices in having ordinary equipment originally, develop, design, can produced polyethylene compound bubble (cushion) membrane in succession. Designs science, practical. Rational  in structure of the machine.




.Characteristic

This machine adopts once-through shaping technique, thus has high efficiency and excellent product quality. This machine set has such features as scientific and reasonable structure design, smooth and reliable running and convenient operation and maintenance.

Polyethylene air-cushion film (also called polyethylene bubble film), which is divided into two kind: ordinary polyethylene air-cushion film and composite polyethylene air-cushion film, is a kind of packing material which has been widely used at present. It not only has good cushioning effect, shock resistance and heat-sealing performance, but also has such advantages as good corrosion resistance and transparency , etc. So it has been widely used for packing, household wares, post parcel, bicycle , polyurethane furniture, etc.

Ⅲ.Application

The bubble film is made of LDPE material. It can be used for various packaging purposes such as moisture proving, dust proving, shock proving, and static prevention. It can also make into laminated films with aluminized film, foamed PE sheet, and paper are the applications of sun shading, heat insulation, and packaging.


Ⅳ.Main Technical Parameter

MODEL

DY-1200

DY-1600

DY-1800

DY-2000

SUITABLE RAW MATORIAL                  HDPE       LDPE     LLDPE

WIDTH OF PRODUCTION

1200

1600

1800

2000

MAIN BUBBLE SPECIFICATION

Φ6*3.2mm φ10*3.6mm φ25*10mm φ30*10mm

BUBBLE ROLLER DIEMETER

                       Φ270 -370

TOTALINSTALLED CAPACITY

55kw

75kw

80kw

80kw

COVER DIMENSIONM

5.65*3.1*3.15

6*3.5*3.15

6.2*3.7*3.15

6*3.9*3.15

OUTPUT

30-60kg/h

60-80kg/h

70-100kg/h

80-120kg/h

GROSS WEIGHT

3.8T

4T

5.5T

6T

Ⅴ.After sale Service:

1) Warranty Time: 1 year, within this period we offer spare part replacement freely if there are any Non-artificial damage on them.

2) Quality: Quality of products will be strictly checked and every machine will be test to ensure it can works well before packaging.

3) Technical services: We will keep contacting with our customers all the time after selling out the machine. Please contact us without hesitation if you need any help on machines.

4) File Services: We offer instruction manual and video to teach you how to using and testing machine
.
