Automatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE Material

Automatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE Material

Automatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE Material
Automatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE MaterialAutomatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE MaterialAutomatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE MaterialAutomatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE MaterialAutomatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE Material
CategoriesFilm Blowing Machine
AlbumView larger image
BrandVinot
ModelSJ50 / SJ55 / SJ60 / SJ65
place of originRuian,Zhejiang,China
Unit PriceUS $ 8800 / piece
FOB portningo
Terms of PaymentL/C, T/T, T/T
Download DOC
Update Time2018-05-27
Detail Information

Automatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE Material

Detailed Product Description
Material:HDPE/LDPE/LLDPEOutput:30 - 110kg / H
L / D Ratio:28 : 1Film Thickness:0.01 - 0.10mm
Heating Power:11 - 21kwFilm Width:100 - 1200mm

Automatic Double Sides Rewinder Of Plastic Film Extruding Machine

Use:

It applicable to the blowing low-density polyethylene (LDPE) high-density polyethylene (HDPE) linear low density polyethylene (LLPE) such as plastic film, widely used in food, clothing, garbage bags, supermarket bag,various plastic package bags,vests bags, cote film,and other civil and industrial packaging,farmland film,and compound thin film or laminating film.



  Optional Device: Auto load

                                Cast aluminum heater

                                 Air shaft

                                 Rotary die device

                                 Double sides winder

                                 Up and down

                                 Pneumatic device

                                 Air compressor



Features:

1. The unit extruder, barrel, screw adopt high-quality steel, nitride tight handling and precision machining, with the best hardness and corrosion resistance, a specially designed screw high yield, good plastic.
2. The main motor adopts frequency control of motor speed to improve the speed regulating stability of main motor and save electricity by 30%. The screw and material barrel adopt 38 chrome-molybdenum aluminum which has been nitrogen treated and the traction frame adopts lifting type. No matter what size the film is, big or small, it can achieve the best effect of cooling.


Main Specification:


MODELSJ50SJ55SJ60SJ65
SCREW DIAMETER(mm)50mm55mm60mm65mm
SCREW L/D28:128:128:1
Reduced diameter of film100-600mm200-800mm300-1000mm400-1200mm
Single-face thickness0.01-0.10mm0.01-0.10mm0.01-0.10mm0.01-0.10mm
Max.Extrusion30-45kg/h40-70kg/h60-100kg/h80-110kg/h
Power of main motor7.5-11kw11-15kw18.5-22kw22kw
Power of traction power1.1kw1.1kw1.5kw1.5kw
Heating Power11kw13kw19kw21kw
Outline diameter4.8*1.9*3.5m5.5*2.1*3.8m6.5*2.3*4.2m6.5*2.5*6.0m
Weight1.5T2T2.3T2.6T



Packaging & Shipping

  • Port: Ningbo
  • Packaging details: With stretch film and bubble film package outside
  • Delivery detail: Within 30 work days after receiving the deposit payment



Details Picture :



Automatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE MaterialAutomatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE MaterialAutomatic Multilayer Blown Film Machine HDPE / LDPE / LLDPE Material
